UNNO Burn Factory

Frame

Model: Unno BURN
Full carbon fiber monocoque construction with 160mm of rear travel, built around a virtual pivot suspension platform. The frame includes an integrated chain guide and seat clamp, motor protector, EnduroMAX bearings, and internal cable routing. Designed with a 12x148mm Boost thru-axle, post mount brake system, and clearance for up to 2.6” tires. Sustainability features include Oceanworks recycled plastic components and recycled rubber frame protectors. Recommended suspension sag: 35% (±5%).

Headset

ACROS Block-Lock
135º steering limit, equipped with CANE CREEK spacers.

Suspension

• Fork:
  Fox 38 Factory
  170mm travel, Kashima-coated stanchions, Grip X2 damper with high- and low-speed compression (HSC/LSC) and rebound (HSR/LSR) adjustability. 44mm offset.

• Rear Shock:
  Fox Float X2 Factory
  230x65mm, Kashima coating, 2-position lever, VVC rebound. Fully adjustable HSC, LSC, HSR, LSR.

Drivetrain

• Rear Derailleur:
  SRAM XX Eagle AXS T-Type (Wireless, 12-speed, silver finish)
  Includes Powerpack battery. Approx. weight: 450g.

• Controller:
  SRAM AXS Pod
  Mounted with Discrete Clamp.

• Crankset:
  SRAM XX Carbon DUB Wide
  Optimized for T-Type drivetrains, 170mm crank arm length.

• Chainring:
  SRAM XX Direct Mount, 34T, 12-speed.

• Cassette:
  SRAM XX XS-1297 T-Type, 10-52T, 12-speed.

• Chain:
  SRAM XX Flat Top, 12-speed, hollow pin design.

Wheelset

• Wheels:
  DT Swiss HXC1501 Spline
  Carbon rims with DT 240 hubs.

  • Front: 29", 30mm inner width

  • Rear: 27.5", 30mm inner width

• Front Tire:
  Continental Kryptotal-F Enduro
  29 x 2.40”, folding bead, Skin SL casing, black sidewalls.

• Rear Tire:
  Continental Kryptotal-R Enduro
  27.5 x 2.40”, folding bead, Skin SL casing, black sidewalls.

Brakes

• Brakeset:
  Formula Cura 4
  Four 18mm pistons per caliper, axial master cylinder, forged aluminum body, SRAM Mixmaster compatible, sintered pads.

  • Hose length: 850mm (front), 2000mm (rear)

• Rotors:
  Formula Monolithic
  203mm front and rear, 2.35mm thickness. Designed for extreme lateral stiffness, noise reduction, and vibration damping.

Cockpit, Dropper & Saddle

• Handlebar:
  DEUX Enduro Integrated Cockpit
  800mm wide, 40mm length, 20mm rise. Integrated stem with hidden wedge and internal fork tube clamp.

• Dropper Post:
  RockShox Reverb AXS (Electronic)
  Left bridge control. Travel by size:

  • 125mm (Size S1)

  • 150mm (Size S2)

  • 175mm (Size S3)

• Saddle:
  Selle Italia SLR Boost Kit Carbonio
